TECHNICAL DATA
Input: unbalanced jack
Sensitivity: OV-15V P2P maximum
Input impedance: 2 M Ω
Power output: about 100 watts
Speaker connections
Input jacks: 1 x 8 Ω, 1 x 16 Ω
FX Send/Return: unbalanced jack
FX Send-Output and FX-Return Input levels dependent on switching
LOW: -10dBU +/-1dB or 0.7V P2P
HI: +4dBU +/-1dB or 3.46V P2P
FX Send-Output impedance: < 1.3kΩ
FX Return-Input impedance: > 18kΩ
Mains voltage range: 100-240V +/- 10 % 50-60 Hz
Power consumption: max. 150 watts
Fuses: internal: 3.15 SB
Ambient operating temperature range:
0 °C to + 35 °C
Logic MIDI control system:
STM 8 S
System interfaces:
Upgradeable with external programming device
BluGuitar® specific, anachronous data protocol.
Dimensions:
Width: 245 mm
Height: 68 mm
Depth: 192 mm
Weight: 1.2 kg
